FPM-302/FPM-302X power meter
MODEL：FPM-302
BRAND：EXFO
This type had been snuffed out,Upgrade model is PX1.
BRAND：EXFO
This type had been snuffed out,Upgrade model is PX1.
Information
This type had been snuffed out,Upgrade model is PX1.
FPM-302/FPM-302X power meter Feature:
-Highly accurate unit offering 10 calibrated wavelengths and reference values
-Power autonomy of 300 hours
-Three-year warranty and recommended calibration interval, for dramatically reduced cost of ownership
-Ergonomic, eye-catching handheld package
FPM-302/FPM-302X power meter Specifications
|
Model
|
FPM-302
|
FPM-302X
|
|
Power meter port
|
Ge
|
GeX
|
|
Power range(dBm)
|
10 to ?60
|
26 to ?50
|
|
Range displayed (dBm)
|
Down to ?65
|
Down to ?50
|
|
Number of calibrated wavelengths
|
10
|
10
|
|
Power uncertainty
|
5 % 1 nW
|
5 % 10 nW
|
|
Resolution (dB)
|
0.01
|
0.01
|
|
Automatic offset nulling
|
Yes
|
Yes
|
|
Warmup time(s)
|
0
|
0
|
|
Display units
|
dB/dBm/W
|
dB/dBm/W
|
|
Automatic wavelength recognition
|
Yes
|
Yes
|
|
Screen refresh rate (Hz)
|
3
|
3
|
|
Tone detection (Hz)
|
270, 1 k, 2 k
|
270, 1 k, 2 k
|
|
Battery life (hours) (typical)
|
> 300
|
> 300
|
|
Warranty and recommended
calibration interval (years)
|
3
|
3
|
|
General Specifications
|
||
|
Size (H x W x D)
|
18.5 cm x 10.0 cm x 5.5 cm
|
71/4 in x 4 in x 21/8 in
|
|
Weight
|
0.4 kg
|
0.9 lb
|
|
Temperature operating
|
?10 C to 50 C
|
14 F to 122 F
|
|
storage
|
?40 C to 70 C
|
?40 F to 158 F
|
|
Relative humidity
|
0 % to 95 % non-condensing
|
|
