BRAND：INNO
Description:
The new features of the INNO IFS-15 fusion splicer include bi-directional viewing operation, a friendly GUI interface, military grade keypad design. The IFS-15 battery capacity has up to 350 splices, more than twice the FSM-60S. The Master Fiber IFS-15 also has an illuminated keypad, zoom heating window and bright LED for night splicing with easy quick change electrodes. All with U.S. service and support.
Highlights:
2.2kg weight (without Battery)
Splicing Method: DACAS
Digital Analysis Core Alignment System
Harsh weather conditions adaptability
Friendly smart GUI
Large Battery capacity: 350 times
Quick optimize menu
High precision splicing
USB master port, easy to upgrade software
Operate in Bi-directional view
Features:
2.8KG weight, light and handy, user friendly, easy to operate
Very fast splicing time, only 9 seconds
Operates in Bi-Directional view.
Real-time calibration of arc-discharge
Large capacity Lithium-Ion Battery
Friendly GUI, easy to operate
Artificial technology, auto discriminate fiber and auto select fusion mode
Auto compensate arc-discharge according to temperature and air pressure
USB master port, easy to upgrade software
Entire environmental protection design conforms to the ROHS standard
High density windproof design, newest fusion technology (High: 168mm, wide: 145mm)
TWO-WAY Multi-Task Support:
180o switching monitor application to match user’s work preference. One can choose his work environment by changing monitor front or back.
Specifcitions:
|
Splicing Method |
Core alignment |
|
Applicable fiber |
SM(ITU-TG.652),MM(ITU-TG.651),DS(ITU-T G.653),NZDS(ITU-T G.655) |
|
Average loss |
SM(0.02dB),MM(0.01 dB),DS(0.04 dB),NZDS(0.04 dB) |
|
Return loss |
>>60 dB |
|
Splice time |
SM fusion average 9s |
|
Cleaved length |
The fiber which coat-diameter is less than 0.25mm:8-16mm |
|
The fiber which coat-diameter is lager than 0.25mm |
least 16mm |
|
Operating environment |
elevation 0-5000meter,95% relative humidity,-10—50C |
|
Magnification |
XY style: 150power |
|
X/Y :300 power |
|
|
Monitor |
2CCD camera system,5inch LCD |
|
Splice Programs |
40 user mode,10 factory preset mode |
|
Coating Diameter |
100-1000um |
|
Clading Diameter |
80-150um |
|
Splice memory |
Can save 2000 record |
|
Fiber Display |
X/Y or XY,single X,Y |
|
Proof test |
2N(standard) |
|
Heating programs |
Preset 10kind heating mode |
|
Heating time |
FP-03 typical heating time 30s |
|
Protection sleeve |
60mm,40mm |
|
Battery |
Typical fusion 350 times |
|
Power supply |
AC 100-240V input or, DC 12-15V |
|
Data output |
USB master device and AV |
|
Wind protection |
The max wind speed 15m/s |
|
size |
168x145x160mm |
|
weight |
2.8Kg |
Standard Package Kit:
|
Name |
Model |
Quantity |
|
Main unit |
IFS-15 |
1 |
|
AC adapto |
ACM-12 |
1 |
|
Charger |
GM-180200 |
1 |
|
Battery pack |
LBT-20 |
1 |
|
AC Power cord |
ACC-15 |
1 |
|
Spare electrode |
E-50 |
1 |
|
Carrying case |
NBX-25 |
1 |
|
High Precision Cleaver |
VF-77 |
1 |
|
Cooling groove |
CG-12 |
1 |
|
User manual |
MB-9XX |
1 |
|
Fiber stripper |
CFS-2 |
1 |
